TPC5120Q

12-Bit 16-Channel 1-MSPS SAR ADC

数据手册

概述
开发资源
应用
订购明细

概述

The TPC5120Q includes a capacitor-based SAR A/D converter with inherent sample and hold. TPC5120Q has 16 channel single-ended inputs.

The devices accept a wide analog supply range from 2.7 V to 5.25 V. Very low power consumption makes these devices suitable for battery-powered and isolated powersupply applications.

A wide 1.7-V to 5.25-V I/O supply range facilitates a glueless interface with the most commonly used digital hosts. The serial interface is controlled by CS and SCLK to make it easy to connect with microprocessors and DSP.

The input signal is sampled with the falling edge of CS. It uses SCLK for conversion, serial data output, and reading serial data in. The devices allow auto sequencing of preselected channels or manual selection of a channel for the next conversion cycle. There are two softwareselectable input ranges (0 V to VREF and 0 V to 2 x VREF), individually configurable GPIOs, and two programmable alarm thresholds per channel. These features make the devices suitable for most data acquisition applications.

The devices offer an attractive power-down feature. This is extremely useful for power saving when the device is operated at lower conversion speeds.

Status

Production
Rating

Automotive
Resolution

12
VDD (V)

2.7~5.5
Channel

16
Throughput Rate (Msps)

1
Architecture

SAR
Input Type

Single-Ended
Multichannel Configuration

Multiplexed
INL (LSB, Max)

±1.5
DNL (LSB, Max)

(-1, 1.5)
Offset Error (LSB, Max)

±4
Gain Error (LSB)

±2
Voltage Input Range (V)

0 to Vref, 0 to 2xVref
IDD (mA)

3.8
Digital Interface

SPI
Temperature Range (℃)

-40 to +125
Package

TSSOP38
